OEM Wood Sawdust Fuel Pellet Making Machine With Electric And Diesel Engine
The advantages of wooddust pellet making machine: 1. High power copper motor, working stable. 2. Vertical feed material centrifugal, feeding more uniform. 3. Stainless steel discharge shell, high temperature corrosion resistance, easy heat dissipation. Application: The raw material can be extruded into pellet. The size of the pellet is: Diameter: 6-12mm. Length: 3-5cm
Features
Products Description
1-Biomass granulator is a kind of biomass energy pretreatmente quipment.
2-lt mainly uses agricultural andforestry processing wastes such as sawdust, straw, ricehusk, bark and other biomass as raw materials, and solidifies them into high-density granular fuel through pretreatment and processing.
3-Biomass granulator is divided into flat model biomass granulator and ring model biomass granulator.
Features of biofuel sawdust pellet machine for farming
1, Home use pellet mill wood pelletizer can produce a variety of wood chips, straw, husk and other raw materials based biomass particles;
2, The use of cold pressing molding, extrusion molding and other molding technology, grease polishing polishing process makes biomass particles beautiful appearance, more compact structure;
3, Rice straw pellet making machine high output, low energy consumption, low noise, low failure, machine fatigue resistance, continuous production, economic and durable;
4, The whole machine is made of special high-quality materials and advanced shaft transmission device, and the key components are made of high-quality alloy steel and wear-resistant materials;
5, The wood stove pellet maker machine mold is placed flat, the mouth is upward, and it is directly into the granulation mold from top to bottom.
More details
Product Parameters
|
Model No. |
Capacity(kg/h) |
Power(kw) |
Pellet Size(mm) |
Weight(t) |
Dimension(mm) |
|
RKL-250 |
100-200 |
15 |
4-6 |
0.5 |
1400*600*1000 |
|
RKL-300 |
150-250 |
22 |
4-6 |
0.65 |
1760*670*1600 |
|
RKL-350 |
100-300 |
30 |
4-8 |
0.76 |
1860*670*1600 |
|
RKL-400 |
300-600 |
37 |
4.5-10 |
2.2 |
1900*850*1750 |
|
RKL-450 |
500-800 |
55 |
4.5-10 |
4.3 |
2300*1100*1900 |
|
RKL-550 |
1000-1500 |
90 |
4.5-12 |
5.5 |
2350*1100*2050 |
Raw Material of rice straw pellet making machine
The wood pellet maker for pellet stove is applied to the material with low adhesiveness and low shaping ,such as the rice husk, sunflower seed husk, peanut shell and other fruit shell branch, trunk, bark and other wood waste; a variety of crop straws, rubber, cement ,ash and other chemical materials. The compress machine for sawdust is widely used in the feed plant, wood processing, fuel plant, fertilizer plant and chemical plant etc. It is the ideal pressing shaping equipment with low investment and high profit.
1. Raw materials diameter requirement : 3-5mm(If large ,crusher machine should be used)
2. Raw materials moisture:15-25%.(If beyond the scope,dryer machine should be used )
2) Raw biomass materials can be waste from sawdust, rice husk, agricultural stalk, straw, peanut shell, sun flower, paper
ect,animal feed materials can be grain, soybean, maize ect, fertilizer materials can be animal manure and so on .
3) Small wood pellet maker machine can press high density pellets , for biomass , density can reach 1.1-1.4ton/m3, diameter can be adjusted from 2-12mm , there is knive installed nearby the outlet door, which can adjust pellet length.
4) when Small Home Use Biomass Wood Pellet Mill works, it is flat die rotates and then take rollers work, but the whole roller assemble is stable . In this way will keep all materials piles up in the center of die , increase machine capacity and pelletizing efficiency.
Company Profile
Packaging and shipping
FAQ
Q1:What is the price of the home wood pellet machine?
A1:It costs approximately US$1,500.00 - 10,000.00
Q2:: How long is the warranty?
A2: We guarantee 18 months after-sales service. If there are any questions when using, calling or mailing us, we will advise on technically sound methods. Free accessories will be provided if needed.
Q3: Can I have my own customized products?
A3: Yes, your customized requirements for color, logo, design, packaging, carton marking, etc. are welcome.
Q4: How to get samples and how long does it take?
A4: Example strategies differ from project to project. Please contact us for detailed information.
Q5: What is the minimum order quantity?
A5: MOQ is different for different items, please contact us to confirm.
Q6: How do I pay for my purchase order?
A6: T/T, L/C at sight, Western Union, MoneyGram.
Q7: What are your payment terms?
A7: For regular order, T/T 30% as deposit and 70% before shipment. Before you pay the balance, we will show you photos of the products and packaging.
