Small Sawdust Biomass Pellet Production Line
This sawdust pellet machine take full advantage of waste material such as wood, sawdust, wood chips, straw, rice husk, peanut shell, etc. help you save money, make money and good for environmenta.
Features
Products Description
Biomass pellet machine line will be all kinds of scattered and finely broken shapeless agricultural and forestry biomass (such as branches, stalks, etc.), after collection, drying, crushing and other pretreatment, under the action of temperature and pressure into a rod, granular molding equipment.
Product Parameters
|
Model |
Capacity(kg/h) |
Power(kw) |
pellet size(mm) |
Weight(t) |
Dimension(mm) |
|
RKL-250 |
100-200 |
15 |
4-6 |
0.5 |
1400*600*1000 |
|
RKL-280 |
150-250 |
22 |
4-6 |
0.65 |
1760*670*1600 |
|
RKL-300 |
100-300 |
30 |
4-8 |
0.76 |
1860*670*1600 |
|
RKL-350 |
300-600 |
37 |
4.5-10 |
2.2 |
1900*850*1750 |
|
RKL-400 |
500-800 |
55 |
4.5-10 |
4.3 |
2300*1100*1900 |
|
RKL-550 |
1000-1500 |
90 |
4.5-12 |
5.5 |
2350*1100*2050 |
|
RKL-800 |
1500-2500 |
160 |
4.5-12 |
6.8 |
3200*1235*2700 |
|
RKL-1200 |
3000-5000 |
320 |
4.5-15 |
19 |
3800*1700*4200 |
Product Analysis
Performance characteristics
1. Reasonable design, compact structure, safety, durability, high production efficiency
2. The whole set of equipment is driven by only one motor to make the rotor rotate at high speed.
3. Equipped with auxiliary equipment such as fans and powder collectors. The fan generates airflow to help the materials disperse and collide better in the crushing chamber, and the powder collector is used to collect and process the generated dust to keep the working environment clean.
Final product
The molded pellet fuel has high specificity, small volume, resistance to combustion, and is convenient for storage and transportation. The density after molding is 1.1-1.5. The calorific value can reach 3400~4800 kcal. It is a solid fuel with high volatile content and low sulfur content.
Application
Biomass pellet machine line can be used as clean energy, which can replace coal and is widely used in thermal power generation fuel, industrial boilers, household heating stoves, etc. It is convenient for storage and transportation, clean and non-polluting when burned, and has little ash without coking.
