How to Describe Biomass Briquette Equipment in Technical Terms

Biomass briquette equipment is best described through its working principle, its key specifications and the product it makes. A clear description lets buyers compare machines on equal terms, plan a production line around the equipment, and discuss technical points with a supplier without ambiguity. This article sets out how to build that description from the parameters that actually decide performance: capacity, installed power, mould configuration, briquette size and operating conditions.

Start with the Working Principle

Briquetting converts low-density residue into a high-density solid fuel. The machine compresses biomass under high pressure and elevated temperature so that the natural lignin softens and binds the particles together without any added glue. A complete description should state which materials the machine accepts - sawdust, wood shavings, straw, rice husk, peanut shell, bagasse and waste paper are common - and which briquette cross-sections and lengths the mould set can produce.

It should also state the pressing method, because screw extrusion, piston and roller types behave differently. Screw extrusion is the most common choice for small and medium fuel plants: a tapered screw forces material through a heated barrel, and the extruded block is cut to length as it leaves the mould.

Key Specifications: Power and Mould Holes

The two most important figures in a machine description are installed power and the number of mould holes, because together they set capacity and electricity consumption. More holes mean more briquettes per revolution, but the motor must be large enough to hold pressing pressure at that rate, so the two numbers are always quoted as a matched pair.

Power (kW) Mould Holes Briquette Size (mm)
45 36 32 x 32 x 50-100
75 48 32 x 32 x 50-100
110 72 32 x 32 x 50-100
132 90 32 x 32 x 50-100
200 120 32 x 32 x 50-100
250 150 32 x 32 x 50-100

Machines in this class form square-section briquettes of about 32 x 32 mm with a length between 50 and 100 mm, a size that suits stoves, furnaces and small industrial boilers. Throughput scales with the frame: a 45 kW machine serves a small workshop, while a 250 kW unit with 150 mould holes is used where several tonnes per hour are required.

Describe the Operating Conditions

A useful description also records what the machine expects from the feedstock. The values most commonly quoted in manufacturers' data are listed below.

Moisture content: about 8 to 15 percent; wetter material produces steam, weak briquettes and unstable extrusion.

Particle size: generally below 5 mm after grinding, so the screw can compress the material evenly.

Barrel temperature: typically 160 to 200 degrees Celsius, which is enough to activate the lignin binder.

Binder: none, because heat and pressure release the natural lignin already present in the biomass.

Power supply: three-phase, sized to the installed motor power with starting margin.

Stating these figures tells the reader what preparation is needed before pressing and prevents a machine from being judged on output achieved with feedstock it was never designed to handle.

Express the Benefits in Measurable Terms

Briquette machines save energy and reduce emissions compared with burning loose biomass, but the description is stronger when the benefits are quantified. Compare the density of the briquette with the density of the loose feedstock, state the moisture reduction achieved by drying, quote the uniform cross-section that keeps the flame stable, and give burn time per unit volume against loose residue. Transport and storage advantages follow from those numbers rather than from adjectives.

How to Compare Two Machines Fairly

When machines are placed side by side, compare output per hour, power consumed per tonne of product, mould configuration, wear resistance of the screw and mould, and the quality of feedstock each machine requires. A lower power-to-capacity ratio normally means lower running cost, but the comparison is only valid when both machines are assessed with the same material at the same moisture. Spare-parts availability and the maintenance interval belong in the comparison too, because the screw, mould and bearings are the parts that wear first.

Frequently Asked Questions

Q: Why is the number of mould holes an important specification?
Mould holes determine how many briquettes are formed in each revolution and therefore set the production rate for a given screw speed; they are matched to motor power.

Q: What raw materials can be briquetted?
Sawdust, wood shavings, straw, rice husk, peanut shell, bagasse and waste paper are all common, provided the material is dry and reasonably fine.

Q: What briquette sizes can the machine produce?
The mould sets the cross-section, typically 32 x 32 mm in this class, and the cutting device sets the length, normally 50 to 100 mm; other moulds can be fitted.

Q: How much electricity does briquetting consume?
Consumption depends on machine size and material. The table gives installed motor power; actual draw is lower because the machine rarely runs at full load continuously.

Q: Is pre-drying always necessary?
Most raw biomass has to be dried to about 8 to 15 percent moisture before pressing. Dry sawdust can sometimes be pressed directly, while fresh wood chips must be dried first.

Q: What maintenance does a briquette machine need?
Check the screw, mould and heating elements regularly, replace worn parts before they damage other components, and lubricate bearings on the recommended schedule.
