Portable Wood Chipper
The wood chipper can also process sugar cane, bamboo and other materials.
Features
Branch Crusher features and uses:
The main raw materials for chipper cutting are small diameter wood, wood harvesting, processing residues (such as branches, boards, laths, round cores, waste veneers, waste wood, etc.). And the machine can also be used to cut non-wood raw materials (such as sugar cane, reed, bamboo, etc.). After the raw materials are cut, they become small pieces of wood of certain specifications, which can be used as fuel or various papermaking materials such as particleboard, medium density board and fiberboard. It has the characteristics of wide application range, diversified raw materials, good quality of cutting wood chips, safety and reliability, simple and convenient operation, and high production efficiency.
Tree shredder
| Model | MK-800 | MK-1000 | MK-1200 |
| Diesel engine | 32HP | 55HP | 80HP |
| Fuel consumption t/L | 4 | 6 | 10 |
| Number of blades | 3 movable knives, 1 static knife | 3 movable knives, 1 static knife | 3 movable knives, 1 static knife |
| Inlet size(mm) | 200*220 | 200*220 | 420*380 |
| host speed(r/min) | 1080 | 1080 | 1800 |
| Capacity | 800-1000kg/h | 1000-1500kg/h | 3-5t/h |
| Finished size (mm) | 2-20 | 2-20 | 2-20 |
| Spray height (mm) | 1800 | 1800 | 2900 |
| Rotation of the discharge hood | 360° | 360° | 360° |
| Size(m) | 2.445*1.265*1.245 | 2.43*1.41*1.48m | 4.1*1.7*2.9 |
| Weight | 828kg | 900kg | 3250kg |
Wood chipper shredder structure:
1. The main frame structure is formed by laser cutting in one step, without splicing panels. Beautiful appearance, sturdy and durable, good performance and long service life.
2. It consists of a feeding interface, upper and lower feeding rollers, and a feeding gap adjustment mechanism. The wood entering from the feeding interface is pressed by the upper and lower feeding rollers and fed into the cutting mechanism at a certain speed to control the size of the cutting wood chips; when processing thick wood, It is adjusted by the feeding gap adjustment mechanism.
3. Install two, three or four flying knives on the tool holder, and fix the flying knives with specially made flying knife bolts through the pressure block. On the cutter roller and rotor that have been precisely dynamically balanced and adjusted, the specific speed ratio ensures better material crushing effect.
4. The equipment is equipped with a fully automatic frequency conversion intelligent feeding system, which can be operated remotely by a single person, greatly saving labor.
Garden wood chipper finished product display
Industrial wood chipper Summary
The wood chipper is a relatively new type of chipper produced by our company. Suitable for particle board, medium density board, wood fiber board, paper making, power plant, boiler and other industries. The product has advanced structure, high slice quality, wide adaptability to raw materials, and easy operation and maintenance. Our company's products are reliable and have been sold to countries all over the world, and have received unanimous praise. I believe you will also be very satisfied with our products. If you choose our products, we can provide good after-sales guarantee, and we will send dispatches every year. Professional technicians will go to your country to solve your problem.
