What Is The Process Of Biomass Pellet Fuel Production Line?
Products Description
Biomass pellet fuel is known for its environmental friendliness, cleanliness, high calorific value, and abundant raw material sources. Its raw materials include a wide range of agricultural waste such as straw and corn stalks, as well as pruning waste from orchards, municipalities, and gardens, and even fruit shells and sawdust.
| Model | Power | Mold Hole | Capacity for industrial solid | Capacity for biomass | Pellet size(mm) |
| MKYK-36 | 45kw | 36 | 0.5-1.0 | 1.0-1.5 | 32*32*50-100 |
| MKYK-48 | 75kw | 48 | 1.0-1.5 | 1.5-2.5 | 32*32*50-100 |
| MKYK-72 | 110kw | 72 | 2.0-2.5 | 2.5-3.5 | 32*32*50-100 |
| MKYK-90 | 132kw | 90 | 2.0-2.5 | 3.5-5.0 | 32*32*50-100 |
| MKYK-120 | 200kw | 120 | 3.0-4.0 | 4.0-6.0 | 32*32*50-100 |
| MKYK-150 | 250kw | 150 | 4.0-6.0 | 6.0-10.0 | 32*32*50-100 |
Agricultural waste, such as straw and corn stalks, as well as pruning waste from orchards, municipalities, and gardens, and even fruit shells and sawdust, is processed under high pressure and high temperature in pelletizing equipment, extruded into cylindrical or square strips, and then cut into 15-50mm segments to produce high-quality biomass pellet fuel. This fuel is not only environmentally friendly and recyclable, but also suitable for use in schools, enterprises, institutions, biomass boilers, and other fields.
▲ Overview of Key Equipment
▲ Chipper Function
The raw material is fed into the chipper via a conveyor. After chipping, the resulting wood chips are conveyed out by a conveyor and stacked accordingly or sent directly to a pulverizer for use in subsequent production processes.
▲ Pulverizer Operation Process
The chipped wood chips are conveyed by a conveyor to the pulverizer for fine grinding. Once the pulverized material meets the requirements for pelletizing, it is sorted and stacked or sent directly to a dryer via a conveyor for further production.
▲ Moisture Control in the Dryer
Biomass pellet fuel has strict requirements for the moisture content of the raw material, which must be kept below 15%. If the moisture content of the raw material is too high, it must be dried before use. The wet raw material is conveyed to the dryer via a conveyor, where it is dried using hot air until the required moisture content is reached before further production.
▲ Pellet Machine Pellet Production Features
The biomass pellet fuel briquetting machine is the core equipment of the production line. This system utilizes a high-quality pellet machine certified by the Ministry of Agriculture. This equipment operates stably, boasts high output, low noise, and low energy consumption.
▲ The Function of the Cooler
After being pressed and formed, biomass pellets reach temperatures as high as 80-90°C. At this point, their structure is relatively loose, making them susceptible to breakage during subsequent processing. To ensure the strength and quality of the pellets, they must be cooled in a cooler until they return to room temperature.
Why choose MIKIM?
Whether it is a new construction or expansion project, or an upgrade and renovation of an existing facility, MIKIM can use its extensive processing expertise and experience to meet your specific requirements at the lowest total cost of ownership.
No matter how special your raw materials are, no matter how limited your plant space is, our engineers can realize the most suitable design to meet your feed processing needs.
For more information on process design, equipment layout, plant construction plan, single machine equipment quotation, turnkey quotation, etc., please feel free to contact us.
Equipment Photos
Certificate of Honor
