Is The Fuel Pellet Production Line Expensive?



What factors determine whether a pellet mill is expensive?

Pellet mill prices range from a few thousand yuan to hundreds of thousands of yuan, with the difference driven by several key factors:

1. Equipment Type and Configuration

There is a significant price difference between ring die pellet mills and flat die pellet mills. The former is more suitable for high-volume industrial use, and therefore naturally has a higher cost.

Configurations such as automatic lubrication, servo feeding systems, and high-efficiency dust removal significantly increase costs, but can improve production capacity and equipment lifespan.

2. Materials and Manufacturing Standards

High-strength alloy steel, precision-forged rollers, and dies are key materials that determine lifespan and forming efficiency. Industry-recognized standards such as Q235B and 42CrMo alloy steel directly influence equipment pricing.

3. Motor and Gearbox Selection

Choosing Siemens standard motors or national standard Class 1 energy-efficiency motors, while requiring a higher initial investment, offers stable operation and low energy consumption, making them key to long-term cost optimization.





Model	Power	Mold Hole	Capacity for industrial solid	Capacity for biomass	Pellet size(mm)
MKYK-36	45kw	36	0.5-1.0	1.0-1.5	32*32*50-100
MKYK-48	75kw	48	1.0-1.5	1.5-2.5	32*32*50-100
MKYK-72	110kw	72	2.0-2.5	2.5-3.5	32*32*50-100
MKYK-90	132kw	90	2.0-2.5	3.5-5.0	32*32*50-100
MKYK-120	200kw	120	3.0-4.0	4.0-6.0	32*32*50-100
MKYK-150	250kw	150	4.0-6.0	6.0-10.0	32*32*50-100



A pellet mill primarily relies on the squeezing force of a pressure wheel against a die to compress the raw material through the die holes. This process involves:
Controlling the raw material moisture content (optimally between 12% and 18%);
Pressure regulation and die hole design determine pellet density and pellet formation rate;
Wear resistance and heat dissipation system design influence the equipment's continuous operation capability.

For this reason, pellet mills with high-quality structural design and manufacturing processes are more efficient in pelletizing complex raw materials such as straw, sawdust, and rice husks. While slightly more expensive, they offer excellent value for money.



If you want to know more about process design, equipment layout, plant construction plan, single-machine equipment quotation, turnkey quotation and other information, please feel free to contact us.





Can rice husks be used to make pellets?
Yes, of course. Rice husks can be used to make pellet fuel. However, it's important to ensure the husks maintain a certain moisture content, around 10%.



What are the uses of wood pellets?
Wood pellets are typically used directly as fuel. These fuel pellets are often used to heat factory boilers and homes. Alternatively, wood pellets can be carbonized in a carbonizer to make charcoal pellets.
