Small Wood Charcoal Brick Pressure Making Machine
A sawdust log maker machine is a specialized piece of equipment that uses a screw shaft to compress and generate heat through friction, converting loose biomass raw materials into high-density block fuel.
Features
Products Description
Sawdust charcoal extruder machine can process wood wastes materials into charcoal efficiently, which is one kind of green biomass fuel. It is good substitute of good raw wood or excellent coal, smokeless, long burning time. Can be used for warming, heating, drying fuel, grilling, etc.
Sawdust charcoal making machine can be driven by electric motor or diesel engine, the raw materials is compressed under high temperature and pressure by the screw extruding. With the intrinsic attributes of the wood materials, under high pressure, wood element in wood materials becomes plastic and makes the fine fiber combined, and then stick solid fuel is formed through the molding tube.
The natural lignin content in the biomass liberated under high temperature serves as glue in briquette process, binding wood materials together, so no need any adhesives.
Advantaqges of Wood Briquette Machine
The mechanical Briquetting procedure is the conversion of agricultural waste into uniformly shaped briquettes (bricks), compressing them into a solid fuel of a convenient shape that can be burned like wood, firewood or charcoal that is easy to use, transport and store.
The major advantage in a Briquetting plant is that it does not require any binder to bind the materials together to form a briquette. Thus it is also called as binder-less technology.
Raw Material: Biomass wastes, such as sawdust, rice husks, coffee husks, rice straw, wheat straw,etc.
Material required: moisture is 8%-12%, size is 3-5 mm.
If the moisture is more than 12%, you need dryer. We have air flow dryer and drum dryer for you to choose.
If material size is more than 5mm, you need hammer mill or wood crusher.
Application
All kinds of biomass material (pasture, sawdust, eucalyptus bark, bran, straw, rice straw, wheat straw, corn stalk, peanut shell, beanstalk, cotton husk, shrub, forest product residual wastes and other wood materials).
Feature:
1.Output forming steady: mechanical ramjet design, used high temperature high pressure ram principle to adjust pressure angel ,make material output without block;
2.Long life : use alloy steel ,vacuum firing craft, improve die life time ;
Product Parameters
|
Biomass Briquette Machine specification |
|
|
Capacity |
1200-1500Kg/Hour |
|
Total Power |
Main Engine Power: 45Kw |
|
Total Power: 61Kw |
|
|
Feeding Raw Materials Size |
Less than or equal to 5mm |
|
Raw Materials Moisture Content |
10-20% |
|
Final Briquette Size |
70-80mm Diameters |
|
Density of Briquette |
10.-1.2g/CM3 |
|
Briquette Moisture Content |
Less than or equal to 12% |
|
Machine Size(L*W*H) |
3.5*1.7*1.8meters |
|
Machine Weight |
7000Kg |
Final product
Customer Cases
Cuban customer's factory on-site test run
Company Profile
Our factory has a robust production capacity tailored to meet a variety of demands in the biomass industry. Utilizing advanced technology, we efficiently process various raw materials such as wood sawdust, oak sawdust, bagasse, fiber palm, straw, rice husk, grass, horse manure, chicken manure, and more.
Packaging and shipping
FAQ
1. Are you manufacturer or trade company ?
We are manufacturer with own factory for many years with CE Certification.
